Focusrite RedNet R1 Dante Monitor Controller & Remote Controller

Overview

The Focusrite RedNet R1 is a professional desktop remote controller designed to provide hands-on control of Focusrite Red audio interfaces and Dante-based monitoring systems. It combines comprehensive monitor control, source selection, immersive audio management, talkback, headphone monitoring, and precision metering in a compact desktop unit.

RedNet R1 can manage monitoring configurations from mono and stereo through surround and immersive formats up to 7.1.4, including Dolby Atmos workflows. It can select and mix sources from Red interfaces, Pro Tools | HD and other DAWs, analogue and digital I/O, ADAT, S/PDIF, and Dante audio networks, providing a central control point for complex professional monitoring systems.

Key Features

• Professional desktop remote controller for Focusrite Red interfaces
• Control of monitoring setups from mono through 7.1.4 immersive configurations
• Support for Dolby Atmos and other immersive audio workflows
• Up to 8 source groups with up to 12 channels per group and 32 channels total
• Routing and mixing to up to 12 monitor output channels
• Level, reference level, cut, dim, mute, sum, spill, and solo controls
• A/B switching between monitoring presets
• Up to four fold-down presets for quick surround and immersive checks
• Custom cue mixes for performers and talent
• Built-in Dante-enabled talkback microphone
• Rear-panel XLR input for an external talkback microphone
• Up to four talkback destination groups with compatible Red interfaces
• High-powered headphone output supporting 32Ω to 600Ω headphones
• Two colour LCD displays for detailed metering and menu navigation
• Footswitch input for talkback, LFE mute, and other functions
• Configuration through Focusrite RedNet Control
• Power over Ethernet or included 12V DC power supply

Comprehensive Monitor Control

RedNet R1 places essential monitoring controls directly at the engineer's fingertips. Dedicated controls provide level adjustment, reference level selection, cut, dim, mute, solo, and source management, allowing complex monitoring systems to be operated quickly without relying solely on computer software.

Flexible Source Selection and Routing

RedNet R1 can access up to 32 available audio channels arranged across as many as eight source groups. Sources can include analogue inputs and outputs, ADAT, S/PDIF, Pro Tools | HD and other DAW connections, Red interfaces, and Dante audio networks.

Multiple sources can be switched, summed, or managed from the front panel, making it practical to compare mixes, monitor individual channels, or move between different production sources during recording, mixing, and post-production.

Immersive and Surround Monitoring

RedNet R1 supports monitoring configurations ranging from mono and stereo to multichannel immersive formats up to 7.1.4. This makes it suitable for Dolby Atmos and other immersive workflows where engineers need fast access to multiple speaker layouts and monitoring configurations.

Monitor Presets and Fold-Downs

An A/B control provides rapid switching between monitoring presets, while up to four fold-down presets allow engineers to check mixes in alternative formats. This makes it easier to verify how an immersive or surround mix translates to different speaker configurations without interrupting the main workflow.

Talkback and Headphone Monitoring

RedNet R1 includes a Dante-enabled talkback system with a built-in microphone and a rear-panel XLR input for connecting an external microphone. When paired with a compatible Red interface, up to four talkback destination groups can be configured. When used with other Dante devices, a single talkback destination group is available.

The high-powered headphone output provides a dedicated monitoring path for checking sources and communicating with performers. It supports headphones from 32Ω through 600Ω, making it suitable for a wide range of professional headphones.

Precision Metering

Two colour LCD displays provide clear visual feedback for source, output, and headphone levels while also guiding users through the controller's menus. This gives engineers detailed monitoring information without requiring constant attention to a computer screen.

RedNet Control

RedNet R1 is configured through Focusrite RedNet Control software, which provides an efficient way to establish monitoring and routing configurations. Once configured, the hardware-focused workflow allows engineers to operate the system directly from the desktop controller.

Footswitch Control

A dedicated 1/4-inch footswitch input provides hands-free control for functions such as talkback management and LFE muting. This can be particularly useful in recording and post-production environments where engineers need quick access to communication or monitoring controls.

Power over Ethernet

RedNet R1 can receive power through Ethernet using IEEE 802.3af Class 0 Power over Ethernet, reducing cabling requirements on the desktop. An included 12V DC power supply provides an alternative power source when PoE is unavailable.

Typical Uses

• Professional recording studios
• Music production and mixing rooms
• Dolby Atmos and immersive audio production
• Surround and multichannel post-production
• Film and television post-production
• Broadcast monitoring systems
• Pro Tools | HD monitoring environments
• Dante audio-over-IP studios
• ADR and Foley facilities
• Professional control rooms and edit suites

Specifications

• Type: Desktop remote monitor and device controller
• Source Groups: Up to 8
• Available Source Channels: Up to 32 total
• Channels per Source Group: Up to 12
• Monitor Output Channels: Up to 12
• Monitoring Formats: Mono, stereo, surround, immersive and up to 7.1.4
• Talkback Input: Built-in microphone and 1 x external XLR microphone input
• External Talkback Mic Gain: 0–55dB
• External Talkback Mic Input Impedance: 3kΩ
• External Talkback Maximum Input: +10dBu
• Headphone Output: 1 x 1/4-inch stereo jack
• Headphone Impedance Range: 32Ω–600Ω
• Headphone Output Impedance: 5Ω
• Headphone Dynamic Range: 108dB A-weighted typical
• Supported Sample Rates: 44.1, 48, 88.2 and 96kHz
• Resolution: 24-bit
• Clock Sources: Internal or Dante Network Master
• Network Connection: 1 x standard RJ45
• Power over Ethernet: IEEE 802.3af Class 0, PoE A or PoE B compatible
• DC Power: 12V, 1.2A
• Power Consumption: 10.3W via PoE / 9W via supplied DC power supply
• Footswitch Input: 1 x 1/4-inch stereo jack
• Software Control: Focusrite RedNet Control

What's Included

• Focusrite RedNet R1
• Locking 12V DC Power Supply
• Ethernet Cable
• Safety Information Sheet
• Focusrite Pro Important Information Guide
• Product Registration Card

Why Choose the Focusrite RedNet R1?

The Focusrite RedNet R1 provides a powerful hands-on control surface for professional Red and Dante monitoring systems. With flexible source routing, immersive monitoring up to 7.1.4, monitor presets and fold-downs, talkback, high-powered headphone monitoring, precision metering, and PoE operation, it gives engineers a streamlined way to manage complex monitoring workflows from a single desktop controller.
