ADAM Audio S5V Flagship Main Monitor
Brand
ADAM
The ADAM Audio S5V is a vertical three-way main monitor built for reference listening in medium-to-large control rooms. Combining a massive 12" ELE woofer with a 4" hybrid midrange and the S-ART tweeter, it delivers 1100W of precision power and full-bandwidth accuracy for elite engineers in Dubai and the GCC.
ADAM Audio S5V: Vertical Precision and Massive Power for Main Monitoring
The ADAM Audio S5V is a vertically oriented 3-way main monitor, meticulously engineered to serve as the definitive reference standard in professional recording and post-production environments. Designed for those who require the raw power of a main system with the analytical detail of a nearfield, the S5V offers a neutral soundstage and breathtaking dynamic range. For premier studios in Dubai and across the GCC, the S5V provides the headroom and clinical accuracy needed to make critical audio decisions with absolute confidence.
Advanced Tri-Amplified Driver Technology
The S5V utilizes a powerful 1100W RMS tri-amplified system to ensure distortion-free playback at any volume:
- 12-Inch ELE HexaCone Woofer: Powered by a 700W PWM amplifier, this long-throw driver uses Symmetrical Magnet Assembly (SMA) technology to deliver pulse-accurate, deep bass down to 25Hz.
- 4-Inch DCH Midrange: A 300W hybrid driver that combines the best characteristics of dome and cone designs, offering unprecedented transparency in the critical vocal and instrument frequencies.
- Handmade S-ART Tweeter: Berlin-built and mounted in a solid aluminum HPS waveguide, it reproduces high-frequency details up to 50kHz with a stable, wide-ranging sweet spot.
Intelligent DSP and Digital Signal Path
Equipped with a high-performance custom DSP engine, the S5V allows for perfect acoustic integration into your UAE studio space:
- In-Room Calibration: 6-band parametric EQ and high/low shelf filters allow you to tailor the response to your specific room conditions.
- Digital Connectivity: Includes an AES3 digital input for a pure, lossless signal path directly from your professional interface or console.
- Remote Control Software: Use the rear-panel USB port to connect a computer and adjust all DSP parameters via the S-Control remote software.
Technical Specifications
- Monitor Type: 3-Way Active Vertical Main Monitor.
- Tweeter: 2" S-ART Ribbon with HPS Waveguide.
- Midrange: 4" DCH Carbon Composite with MPS Waveguide.
- Woofer: 12" ELE HexaCone Woofer.
- Total Power: 1100W RMS (700W LF, 300W MF, 100W HF).
- Frequency Response: 25 Hz – 50 kHz.
- Maximum SPL: ≥128 dB (per pair at 1m).
- Crossover Frequencies: 250 Hz / 3 kHz.
- Inputs: Analog XLR, Digital AES3 (In/Out).
- Dimensions (HxWxD): 698 mm x 390 mm x 520 mm.
- Weight: 52 kg (114.5 lbs) per unit.
Experience the pinnacle of vertical monitoring. Order the ADAM Audio S5V from Gigstore today and achieve a new level of sonic transparency.
