Neumann KM 130 Omnidirectional Miniature Condenser Microphone with AK 30 Capsule
Brand
NEUMANN
Bring pristine, uncolored acoustic capture and legendary German engineering to your studio roster with the Neumann KM 130. As a highly coveted masterpiece from Neumann’s historic KM 100 modular miniature microphone series, this premium small-diaphragm condenser is configured with a true free-field equalized omnidirectional capsule. It stands as a top-tier reference choice for classical recording, drum overheads, grand pianos, string ensembles, and ambient room tracking where absolute low-end integrity and spatial realism are required.
Neumann KM 130 Miniature Omnidirectional Condenser Microphone with AK 30 Capsule
The Neumann KM 130 is a professional miniature condenser microphone from the historic Neumann KM 100 modular microphone series. Combining the KM 100 output stage with the AK 30 diffuse-field equalized omnidirectional capsule, the KM 130 delivers exceptionally natural sound reproduction, accurate spatial detail, and the renowned precision associated with Neumann small-diaphragm microphones. Designed for professional recording applications, the KM 130 is ideal for classical music, orchestral recording, acoustic instruments, ambience capture, and stereo microphone techniques where a natural and open sound character is required.
The KM 130 features the AK 30 pressure transducer capsule with an omnidirectional pickup pattern optimized for diffuse-field recording. Its carefully engineered acoustic response provides excellent low-frequency accuracy and a smooth, natural reproduction of the recording environment, making it especially suitable for capturing the realistic character of concert halls, ensembles, and acoustic instruments.
Historic Neumann KM 100 Modular Microphone System
The KM 130 is part of Neumann's first modular small-diaphragm microphone system, the KM 100 series. The modular design allows the microphone capsule and output stage to be separated, providing exceptional flexibility for professional recording setups. Compatible accessories include extension cables, capsule mounts, swivel adapters, stereo mounting solutions, and other installation options for studio, stage, film, and broadcast applications.
The compact construction of the KM 100 system allows the microphone to be positioned discreetly in challenging recording environments, including overhead placements, concert halls, film locations, and installations where minimal visual presence is required.
Natural Omnidirectional Sound Capture
The AK 30 capsule uses a pressure transducer design with a diffuse-field equalized omnidirectional characteristic. Unlike directional microphones, the KM 130 captures sound equally from all directions, preserving the natural acoustic environment and providing excellent depth and realism.
The microphone maintains linear sensitivity at low frequencies and offers smooth frequency response characteristics, making it particularly effective for distant microphone placement, stereo A-B configurations, room ambience recording, and detailed acoustic instrument capture.
Key Features
- Professional miniature condenser microphone from the Neumann KM 100 modular system.
- Combines KM 100 output stage with AK 30 omnidirectional capsule.
- Diffuse-field equalized omnidirectional pickup pattern.
- Natural and transparent sound reproduction.
- Excellent spatial accuracy and room ambience capture.
- Modular capsule and output stage design.
- Compatible with Neumann KM 100 system accessories.
- Compact design for discreet professional microphone placement.
- Transformerless output circuitry for clean signal transmission.
- Suitable for mono, stereo, and specialized recording techniques.
Ideal Applications
- Classical music recording
- Orchestral recording
- Concert hall ambience recording
- Acoustic instrument recording
- Piano recording
- Strings and percussion
- Room microphone applications
- A-B stereo recording techniques
- Broadcast and film production
- Professional location recording
Technical Specifications
- Product Type: Miniature condenser microphone
- Series: Neumann KM 100 Modular Microphone System
- Capsule: AK 30
- Acoustical Operating Principle: Pressure transducer
- Polar Pattern: Omnidirectional
- Frequency Response: 20 Hz – 20 kHz
- Sensitivity: 12 mV/Pa
- Equivalent Noise Level (A-weighted): 16 dB-A
- Signal-to-Noise Ratio (A-weighted): 78 dB
- Maximum SPL: 140 dB
- Maximum SPL with preattenuation: 150 dB
- Rated Impedance: 50 Ω
- Rated Load Impedance: 1 kΩ
- Power Requirement: 48 V phantom power (P48)
- Current Consumption: 2 mA
- Output Connector: XLR 3-pin
- Diameter: 22 mm
- Length: 92 mm
- Weight: 80 g
Why Choose the Neumann KM 130?
The Neumann KM 130 remains a respected professional microphone for engineers who require accurate, natural, and detailed omnidirectional sound capture. Its AK 30 capsule, modular KM 100 architecture, compact design, and precise acoustic performance make it a valuable tool for classical recording, ambience capture, acoustic instruments, and stereo microphone techniques. Built on Neumann's renowned engineering standards, the KM 130 delivers the realism, reliability, and sonic transparency expected from a professional miniature condenser microphone.
