dBTechnologies DVA S10 DP 18" Active Bandpass Subwoofer
Brand
D B TECHNOLOGIES
The dBTechnologies DVA S10 DP is a high-output 1000W RMS 18-inch active bandpass subwoofer engineered for groundstacked and flown line array sound reinforcement systems delivering up to 136 dB Max SPL.
Deliver massive, punchy low frequencies to your live setups with the dBTechnologies DVA S10DP, a high-performance active bandpass subwoofer engineered for professional touring rigs, live music venues, and scalable line array integrations.
Key Features & Engineering
- Digipro® Class-D Amplification: Powered by a robust 1000W RMS digital amplifier designed for maximum energy efficiency, high thermal stability, and deep bass output.
- 18-Inch Bandpass Design: Houses a high-generation 18" woofer with a 4" voice coil inside a heavy-duty multiplex birch plywood cabinet to generate massive acoustic pressure down to 40 Hz.
- Cardioid Setup Capability: Supports directional low-frequency configurations using an optional SDD delay module to prevent unwanted bass spill back onto the stage.
- Versatile Crossover & Routing: Includes an active stereo crossover with selectable cutoff frequencies (90 Hz or 120 Hz with a 24 dB/octave slope) and a phase switch (0°/180°).
Technical Specifications
| Speaker Type | Active Bandpass Subwoofer |
|---|---|
| Frequency Response [+/- 3 dB] | 40 - 120 Hz |
| Max SPL | 136 dB |
| Low Frequency Driver (LF) | 18" Woofer (4" Voice Coil) |
| Amplifier Technology | Digipro® Class-D |
| RMS Power | 1000 W |
| Controller | Analog with RMS, Peak, and Thermal Limiters |
| Crossover Frequencies | 90 Hz or 120 Hz (24 dB/octave) |
| Enclosure Material | Multiplex Birch Plywood |
| Rigging & Mounting | Integrated hardware for SRK-10 fly kit; M20 pole mount on top |
| Dimensions (W x H x D) | 515 mm x 640 mm x 720 mm (20.6 in x 25.6 in x 28.8 in) |
| Weight | 48 kg (105.82 lbs) |
